60/CG

Welded Metal Bellows, Inherently Balanced , Independent of Direction of Rotation
Seal series 60/CG
Standard Style
Face Materials
Silicon Carbide, Tungsten Carbide, Carbon.

Metal Parts
AISI 316, Carpenter 42

Welded Bellows : AM 350

Secondary Seals
bullet   Grafoil

Applications
bullet   Petrochemicals
bullet   Refineries

Seal Characteristics
bullet   Single acting
bullet   Independent of direction of Rotation
bullet   Inherently Balanced
bullet   Welded Metal Bellows
Operating Limits
Shaft Diameterd1:  19 …100 mm
Pressure pp:  20 bar
Temperaturet:  -20 … +400 o C
Velocityv:  20 m/s.

Seal series 60/CG is welded metal bellow cartridge seal is used in chemical, petrochemical and refinery process pumps for high temperature/moderate pressure applications. This bellow seal is constructed by welding a series of diaphragms together at the edges to form a bellows unit. The bellows unit eleiminates the need for springs, dynamic secondary seal and provides flexibility to the seal face in addition to compensating for seal face wear.

1258614939fd107bec4a5eaaed6441a46280dcc929
127709162160CG
